In the real world, XOR gates only have two inputs, so a four-input XOR function has to be created using three XOR gates arranged as two levels of logic. One-to-many versus many-to-one implementationsĬonsider the case of an 8-bit LFSR, for which the minimum number of taps that will generate a maximal-length sequence is four.
There are also twenty 4-tap combinations, twenty-eight 6-tap combinations, and ten 8-tap combinations that satisfy the maximal-length criteria. For example, in the case of a 10-bit LFSR, there are two 2-tap combinations that result in a maximal-length sequence: and.
As was previously noted, alternative tap combinations may also yield maximum-length LFSRs, although the resulting sequences will vary. Taps for maximal length LFSRs with 2 to 32 bits.The taps are identical for both XOR-based and XNOR-based LFSRs, although the resulting sequence will of course differ. These values are presented for your delectation and delight in Fig 4 (the * annotations indicate sequences whose length is a prime number).Ĥ. The author created a simple C program to determine the taps for maximal-length LFSRs with 2 to 32 bits. The problem is weeding out the ones that do from the ones that don’t, because badly chosen taps can result in the register entering a loop comprising only a limited number of states. Each LFSR supports a number of tap combinations that will generate maximal-length sequences.
